Product Introduction：

Overview

The Honeywell CC-TAIX11 51308365-175 is a high-reliability redundant analog input module (RAIM) designed for Experion PKS and C300 control systems. It provides precise measurement of analog signals including current, voltage, and HART-compatible inputs, ensuring continuous and accurate data acquisition for critical industrial processes.

General Information

Part Number: 51308365-175

Manufacturer: Honeywell

Brand Origin: United States

Series: CC-TAIX11

Type: Redundant Analog Input Module

Channels: 16 (12 single-ended, 4 differential)

Signal Type: 4–20 mA, 0–10 V DC

Mounting: Series C I/O baseplate or C300 system chassis

Application: Industrial process monitoring and automation

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: Approx. 5 W

Input Impedance: 250 Ω for current, >10 MΩ for voltage

Accuracy: ±0.25% of full scale

Protection: Surge and reverse polarity protection

Indicators: LEDs for module status and fault

Communication & Interface

Interface Type: Redundant I/O communication link

Protocols Supported: FTE / ControlNet

Diagnostics: Channel fault detection, line-break detection, self-test

Sampling Rate: 50 ms per channel

Isolation: Channel-to-channel and channel-to-system galvanic isolation

Environmental

Operating Temperature: 0°C to +60°C

Storage Temperature: −40°C to +105°C

Humidity: 5% to 95% RH, non-condensing

Protection Class: IP20

Dimensions & Weight

Dimensions: 145 × 130 × 40 mm

Weight: Approx. 0.35 kg
