Honeywell FC‑TSAI‑1620 | 16‑Channel Analog Input Price Advantage Original

Brand：Honeywell DCS

Item No.：Honeywell FC-TSAI-1620

Product origin：USA

Dimensions:210 × 70 × 60 mm

Weight:0.3 kg

Original overseas introduction, test assistance instructions support, stable and reliable service

Product inventory is continuously updated, and order needs are quickly responded to. Welcome to call for consultation!

Product Introduction：

Overview
The FC‑TSAI‑1620 is a 16‑channel field termination assembly module for analog input signals (0/4‑20 mA) used in safety control systems. Brand: Honeywell. Country of Origin: USA.

General Information
Part Number: FC‑TSAI‑1620
Manufacturer: Honeywell Safety Manager Systems
Brand: Honeywell
Country of Origin: USA
Type: Field Termination Assembly – Analog Input
Channels: 16 (in two groups of 8 with common 0 V)
Function: Provides secure field wiring termination and signal conditioning for analog input modules in safety systems

Power Specifications
Power Supply: External 30 V DC supply, ~3 mA (without input loop loads)
Input Current Range: 0‑25 mA per channel
Input Resistance: 250 Ω (±1%)
Transmitter Supply Output: 270 Ω (±5%) series resistance for passive transmitters; ignition current per channel <120 mA at 30 V DC

Communication & Interface
Signal Type: Current inputs 0/4‑20 mA
Interface: Connects via system interconnect cable to analog input module
Field Termination: Screw terminals for each channel and cable shield connections
Monitoring: Terminal board monitors external power supply status for safety‑related loops

Environmental
Operating Temperature: ‑20 °C to +70 °C
Storage Temperature: ‑40 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Installation: DIN rail or cabinet field termination setup in industrial control systems

Dimensions & Weight
Dimensions (L × W × H): Approx. 210 × 70 × 60 mm
Weight: Approx. 0.3 kg

Genuine new stock, backed by reliable supply and responsive customer service.

The product import process is stable, the delivery speed is flexible and controllable, and there are real discounts for bulk purchases.
