Product Introduction：

Overview

The OVATION 1C31099H01 is an analog input module used in Emerson’s OVATION Distributed Control System (DCS). It acquires analog signals from field transmitters and converts them into digital data for DCS processing. Designed for stable operation, high-accuracy measurement, and integrated diagnostics, it supports reliable long-term performance in industrial automation environments.

General Information

Part Number: 1C31099H01
Manufacturer: Emerson
Series: OVATION I/O Modules
Type: Analog Input Module / Interface Module
Mounting: Rack installation within OVATION I/O chassis
Technology: Signal conversion, isolation, diagnostic monitoring

Power Specifications

Supply Voltage: 5 V DC or 24 V DC via chassis backplane (varies by chassis type)
Power Consumption: ≤ 6 W
Input: Powered through backplane
Protection: Overvoltage protection and reverse-polarity protection
Indicators: LEDs for power, module status, and fault

Communication & Interface

Field Signal Input: Supports standard analog signals such as 4–20 mA or 1–5 V (model dependent)
Controller Interface: Converts analog field signals to OVATION-compatible digital data
Diagnostics: Signal failure detection, channel integrity monitoring, and module health reporting
Operator Interface: LEDs for power, communication, and fault indication
Reset Features: Supports software-based soft reset

I/O & Channels

Analog Input Channels: Up to 8 channels per module
Relay / Output Channels: None
External Load Support: Not applicable

Environmental

Operating Temperature: 0 to 55 °C
Humidity: 10–90% RH, non-condensing
Protection Rating: IP20 industrial cabinet environment

Dimensions & Weight

Dimensions (L × W × H): 160 × 40 × 120 mm
Weight: ~0.45 kg
