Woodward 9905-976 | Overspeed Protection Module New In Stock New In Stock

Brand：Woodward PLC

Item No.：Woodward 9905-976

Product origin：USA

Dimensions:483 × 310 × 143 mm

Weight:2.3 kg

The channel is regular, the test instructions are complete, and the service is responsive

Tens of thousands of models are in sufficient stock, and the spot is shipped quickly. Welcome to consult!

Product Introduction：

Overview

The Woodward 9905-976 is an overspeed protection module designed for turbines, compressors, and other high-speed rotating machinery. It continuously monitors shaft speed using redundant inputs and fail-safe logic, triggering a trip or shutdown when an overspeed condition is detected.

General Information

Part Number: 9905-976

Manufacturer: Woodward

Brand / Country of Origin: Woodward / USA

Type: Overspeed Protection / Safety Module

Series: ProTech 203

Mounting: Panel or rack-mount in control cabinet

Technology: Triple-channel speed sensing with two-out-of-three voting logic for fail-safe overspeed trip

Power Specifications

Supply Input: 120 V AC or 90–150 V DC (depending on module variant)

Power Consumption: ~7.25 W under normal operation

Protection: Internal protection circuitry ensures safe operation under industrial conditions; triggers reliable shutdown if overspeed is detected

Communication & Interface

Speed Input: Three independent magnetic-pickup or encoder inputs for redundant speed measurement

Voting Logic: Two-out-of-three hardware voting ensures single sensor fault does not cause false trips

Output: Relay outputs for trip/shutdown action, with optional alarm/status outputs

Operator Interface: Front-panel keypad and display for setting trip speeds, viewing status, and diagnostics

Environmental

Operating Temperature: –25 to +60 °C

Humidity & Conditions: Designed for industrial environments; module housing and electronics suitable for turbine and generator control systems

Dimensions & Weight

Dimensions (W × H × D): 483 × 310 × 143 mm

Weight: ~2.3 kg
