Product Introduction：

Overview
The Woodward CSC3HUWC2B2 is a control switch module designed to provide operator-level manual control for engine, turbine, or generator control systems. It acts as a human-machine interface, enabling functions such as start, stop, mode selection, and possibly manual override — linking operator inputs to the control system logic.

General Information
Part Number: CSC3HUWC2B2
Manufacturer: Woodward
Brand / Country of Origin: Woodward / USA
Type: Control Switch / Operator Interface Module
Series: CSC (Control Switch Modules)
Mounting: Panel-mount or console-mount installation within control cabinet or operator console
Technology: Switch and logic‑interface assembly compatible with Woodward control systems

Power Specifications
Supply Voltage: 24 V DC nominal
Power Consumption: Minimal — only powers internal switch logic for operator interface
Protection: Designed for industrial environments with isolation, surge protection, and transient suppression
Indicators: May include status LEDs or indicator lights to show module mode or readiness (depending on system implementation)

Communication & Interface
Input Controls: Manual buttons or switches for functions such as start, stop, mode select, manual override, reset, etc.
Output Signals: Digital logic signals compatible with Woodward controller or relay modules — used to convey operator commands to the control system
Integration: Designed to interface with Woodward control bus or discrete input logic depending on system layout

Environmental
Operating Temperature: –20 °C to +70 °C
Humidity: Up to 95% RH, non‑condensing
Protection Rating: Suitable for industrial control panel environment / protected console installation

Dimensions & Weight
Dimensions (L × W × H): ~120 × 80 × 50 mm
Weight: ~0.5 kg
