Honeywell CC-PAIH02 51405038-375 High-Level Analog Input Module Efficient delivery New In Stock

Brand：Honeywell DCS

Item No.：Honeywell CC-PAIH02 51405038-375

Product origin：USA

Dimensions:102 × 80 × 128 mm

Weight:0.12 kg

Clear and reliable product source, support for third-party testing, complete after-sales support

Rich spot models, support for quick docking of procurement needs, welcome to inquire!

Product Introduction：

Overview
The Honeywell CC-PAIH02 (51405038-375) is a high-level analog input module for Honeywell Experion PKS and other industrial control systems. It supports HART 7 communication and provides accurate, isolated analog signal acquisition from field devices.

General Information

Manufacturer: Honeywell

Origin: United States

Model Number: CC-PAIH02

Part Number: 51405038-375

Type: High-Level Analog Input Module

Protocol: HART 7

Applications: Process automation, safety instrumented systems (SIS), industrial monitoring

Electrical Specifications

Input Channels: 16 (12 single-ended, 4 differential)

Input Types: 4–20 mA, 0–5 V, 1–5 V, 0.4–2 V (through 250 Ω resistor)

Resolution: 16-bit

Accuracy: ±0.075% full scale (23.5 °C ±2 °C); ±0.15% full scale (0–60 °C)

Input Impedance: >10 MΩ (voltage inputs)

Common Mode Voltage: −6 to +5 V peak

Common Mode Rejection Ratio: 70 dB

Input Scan Rate: 50 ms

Power Consumption: 1.2 W per channel

Isolation: 1000 V RMS (channel-to-channel)

Operating Temperature Range: −40 °C to +70 °C

Environmental Specifications

Humidity: 5–95% RH, non-condensing

Protection Rating: IP20 (installed in standard rack/cabinet)

Installation Environment: Industrial control cabinet, DIN-rail or rack mount

Dimensions & Weight

Dimensions (L × W × H): 102 × 80 × 128 mm

Weight: Approx. 0.12 kg
