Honeywell CC-PAIH51 51410069-275 High-Level Analog Input Module Price Advantage Unbelievable Prices!

Brand：Honeywell DCS

Item No.：Honeywell CC-PAIH51 51410069-275

Product origin：USA

Dimensions:102 × 80 × 128 mm

Weight:0.12 kg

Original imported channel supply, support for testing instructions, worry-free after-sales

A wide range of spot models, support for quick docking of purchasing needs, welcome to inquire!

Product Introduction：

Overview
The Honeywell CC-PAIH51 (51410069-275) is a high-level analog input module designed for Honeywell Experion PKS and other control systems. It provides precise, isolated acquisition of analog signals and supports HART communication for smart field devices in industrial automation and process control applications.

General Information

Manufacturer: Honeywell

Origin: United States

Model Number: CC-PAIH51

Part Number: 51410069-275

Type: High-Level Analog Input Module

Protocol: HART

Applications: Process automation, safety instrumented systems (SIS), industrial monitoring

Electrical Specifications

Input Channels: 16

Input Signal Types: 4–20 mA, 0–20 mA, ±10 V DC

Resolution: 16-bit

Accuracy: ±0.1% of full scale

Input Impedance: >10 MΩ (voltage inputs)

Common Mode Voltage: −6 to +5 V peak

Common Mode Rejection Ratio: 70 dB

Scan Rate: 50 ms per channel

Power Consumption: 1.2 W per channel

Isolation: 1000 V RMS (channel-to-channel)

Operating Temperature Range: −40 °C to +70 °C

Environmental Specifications

Humidity: 5–95% RH, non-condensing

Protection Rating: IP20 (installed in standard rack/cabinet)

Installation Environment: Industrial control cabinet, DIN-rail or rack mount

Dimensions & Weight

Dimensions (L × W × H): 102 × 80 × 128 mm

Weight: Approx. 0.12 kg

Genuine brand-new products, available now with transparent price quotes.

The product channel is compliant, inventory is sufficient, delivery response is efficient, and bulk orders enjoy bargaining rights.
