GE DS200FGPAG1AGD Gate Pulse Amplifier Board Price Advantage 100% New

Brand：GE Fanuc PLC

Item No.：GE DS200FGPAG1AGD

Product origin：USA

Dimensions:508 × 406 × 229 mm

Weight:3.6 kg

Original overseas introduction, testing assistance and explanation support, stable and reliable service

Ten thousand models are in stock, quickly matching needs, welcome to call for cooperation!

Product Introduction：

Overview
The GE DS200FGPAG1AGD is a Gate Pulse Amplifier Board within the GE Mark V turbine control system. It provides gate power for one phase of an SCR bridge, monitors SCR status, and converts AC power to DC. This module is integral to the Load Commutated Inverter (LCI) used in turbine control applications.

General Information

Part Number: DS200FGPAG1AGD

Product Name / Model: Gate Pulse Amplifier Board

Manufacturer: General Electric (GE)

Country of Origin: United States

Series / Module Type: Mark V / Gate Pulse Amplifier

Type: Control Board

Mounting: Installed in the turbine control system rack

Application Area: Turbine control systems utilizing Load Commutated Inverters

Electrical Specifications

Input Voltage: 120 Vrms ±20%, 50/60 Hz

Power Consumption: Approximately 350 VA maximum

Gate Driver Circuits: Two independent circuits to manage gate pulses for SCRs

Fiber-Optic Connectors: 15 total (1 transmitter and 14 receivers) for robust communication links

Test Points: 30 total (9 for Gate A, 9 for Gate B, and 12 for Cell Status)

Protection: IP50 (Dust and moisture resistant)

Compatibility: Not backwards compatible

Environmental

Operating Temperature: -20°C to +70°C

Storage Temperature: -40°C to +85°C

Humidity: Up to 95%, non-condensing

Cooling: Natural convection

Dimensions & Weight

Dimensions (L × W × H): Approximately 508 × 406 × 229 mm

Weight: Approximately 3.6 kg (8 lbs)

All our inventory is brand new, original, and ready for shipping.

This product is in stock, with fast response, flexible price range, and supports communication based on quantity.
