Honeywell 8C-TAOX51 51306983-175 Analog Output Module Trusted supplier Fast Shipping!

Brand：Honeywell DCS

Item No.：Honeywell 8C-TAOX51 51306983-175

Product origin：USA

Dimensions:145 × 120 × 65 mm

Weight:0.25 kg

Original imported channel supply, support for testing instructions, worry-free after-sales

The inventory covers multiple brands and series, supports fast delivery, welcome to call for negotiation!

Product Introduction：

Overview
The Honeywell 8C-TAOX51 (51306983-175) is a 16-channel analog output I/O module for Honeywell Series-8 / C300 systems. It provides 4–20 mA (and voltage) outputs, supports HART signalling, and includes channel-level diagnostics and configurable fail-safe behaviour for process control applications.

General Information

Part Number: 51306983-175 / 8C-TAOX51

Product Name / Model: 8C-TAOX51 Analog Output Module

Manufacturer: Honeywell

Country of Origin: United States

Series / Module Type: Series-8 analog output I/O module

Type: Analog output (I/O card / IOTA form factor)

Mounting / Format: Backplane / rack module (IOTA slot)

Application Area: DCS outputs, valves/actuators, field signaling in process plants

Electrical Specifications

Channels: 16 analog outputs

Output Types: 4–20 mA and 0–10 V (configurable) with HART overlay on current outputs

Output Range (example): configurable approx. 2.9–21.1 mA for HART compatibility

Max open-circuit voltage: 22 V

Resolution: 12-bit (typical)

Accuracy (typical): ±0.1% to ±0.35% of full scale depending on calibration/state

Response Time: settles within 1% in ≈80 ms

Diagnostics / Protection: open-wire detection, channel fault reporting, conformal coating for contamination resistance

Fail-safe (FAILOPT): configurable per channel (HOLD last or drive to preset safe value)

Environmental

Operating Temperature: −40 °C to +70 °C

Storage Temperature: −55 °C to +85 °C

Humidity: up to 95% RH, non-condensing

Cooling: natural convection (rack cooling)

Protection: conformally coated option for improved resistance to moisture/dust/chemicals; intended for cabinet/I/O rack installation (not standalone weatherproof)

Dimensions & Weight

Dimensions (L × W × H): 145 × 120 × 65 mm

Weight: ~0.25 kg

Authentic factory-sealed items, backed by prompt support.

The product is imported, with complete information, fast delivery, and price advantages. Bulk purchases can be negotiated.
