Honeywell 8C-SDOX01 51307051-175 Digital Output Module 12-Month Warranty 30-Day Returns！

Brand：Honeywell DCS

Item No.：Honeywell 8C-SDOX01 51307051-175

Product origin：USA

Dimensions:31.8 × 63.5 × 12.7 mm

Weight:0.113 kg

Original overseas introduction, testing assistance instructions support, stable and reliable service

Flexible stock of various models, support for rapid response, welcome to cooperate and communicate!

Product Introduction：

Overview

The Honeywell 8C-SDOX01 (Part No. 51307051-175) is a relay extension module for the Series 8 I/O system. It provides isolated dry-contact outputs (Form-C) to control higher voltage or current loads while keeping the digital I/O module signals isolated from field wiring.

General Information

Part Number: 51307051-175 / 8C-SDOX01

Product Name / Model: 8C-SDOX01 Relay Extension Module

Manufacturer: Honeywell

Country of Origin: United States

Series / Module Type: Series 8 Digital Output Relay Extension

Type: Relay Extension / Digital Output Module

Mounting / Format: 15″ IOTA compatible module

Application Area: Control systems, DCS, field relay outputs

Electrical Specifications

Number of Output Channels: 32 (Form-C SPDT contacts)

Contact Rating (Resistive): 5 A @ 125/250 VAC; 3 A @ 30 VDC

Contact Rating (Inductive): 2 A @ 125/250 VAC (PF 0.4)

Isolation (Channel to Logic Common): 1,500 VAC RMS

Turn-On Time / Turn-Off Time: Max 20 ms each

Minimum Load: 10 mA at 5 V DC

Inrush Capability: Up to 10 A for 4 s at 10% duty

Output Link: Three terminals per channel (NO, NC, COM)

LED Indication: Each channel has indicating LED

Environmental

Operating Temperature: –40 °C to +70 °C

Storage Temperature: –40 °C to +85 °C

Relative Humidity: 5% to 95%, non-condensing

Atmospheric Protection: Conformal coated for moisture, dust, and chemical resistance

Certification / Hazardous Area Rating: Zone 2, Ex ec nC IIC T4 Gc (relay extension board only)

Dimensions & Weight

Dimensions (L × W × H): 31.8 × 63.5 × 12.7 mm

Weight: 0.113 kg
