GE IS200ECTBG2A Exciter Control Shelf life 1 year Original

Brand：GE Fanuc PLC

Item No.：GE IS200ECTBG2A

Product origin：USA

Dimensions:150 x 76 x 90 mm

Weight:0.34 kg

Original overseas introduction, test assistance instructions support, stable and reliable service

Regular models are in stock for a long time, and the inventory is stable. Welcome to inquire about the price!

Product Introduction：

Overview

The GE IS200ECTBG2A is an Exciter Contact Terminal Board (ECTB) designed for the EX2100 Excitation Control System, part of the GE Speedtronic Mark VI turbine control series. It provides a reliable interface between the excitation system and external contact inputs/outputs, ensuring accurate turbine control and protection.

General Information

Manufacturer: General Electric (GE)

Country of Origin: United States

Product Category: Exciter Control / Terminal Board

Model / Type: IS200ECTBG2A

Series: EX2100

Revision: G2

Application: Turbine excitation systems, industrial automation

Electrical Characteristics

Relay Control Voltage: 24 V DC

Wetting Voltage: 70 V DC

Relay Break Characteristic: 28 V DC

Customer Power: 125 V DC

Operational Mode: Simplex

I/O Configuration

Contact Inputs: 6

Contact Input Voltage: 70 V DC

Contact Outputs: 6

Trip Contact Outputs: 2

Form C Relay Outputs: 4

Environmental Conditions

Operating Temperature Range: 0 °C to +55 °C

Storage Temperature Range: −40 °C to +85 °C

Humidity: Up to 95% RH, non-condensing

Dimensions & Weight

Dimension: 150 x 76 x 90 mm

Weight: 0.34 kg

Reliable stock of authentic brand-new items, with continuous customer support for quotations.

The product has a cost-effective advantage, timely supply, and a large quantity has a step-by-step discount space.
