Product Introduction：

Overview

The Honeywell 8C-PAIMA1 51454473-175 is a 16-channel low-level analog input module designed for use in Honeywell's Series 8 C300 control systems. It interfaces with thermocouple (TC) and Resistance Temperature Detector (RTD) sensors to provide accurate temperature measurements in industrial applications.

General Information

Part Number: 8C-PAIMA1 51454473-175

Manufacturer: Honeywell

Series: Series 8 C300

Module Type: Analog Input Module (AI)

Input Channels: 16 isolated channels

Mounting: Rack-mounted in Series 8 I/O chassis

Input Specifications

Input Types:

Thermocouple (TC): Types J, K, T, E, R, S, B

RTD: 2-wire, 3-wire, and 4-wire configurations

Input Range:

TC: -200°C to +850°C

RTD: -200°C to +400°C

Accuracy: ±0.15% of full scale

Resolution: 16-bit A/D conversion

Signal Conditioning: Cold-junction compensation, linearization, filtering

Power and Environmental

Supply Voltage: 24 V DC

Power Consumption: Approximately 6.5 W

Operating Temperature: -40°C to +70°C

Storage Temperature: -40°C to +85°C

Humidity: 5% to 95% RH, non-condensing

Protection Rating: IP20 (for installation inside an industrial cabinet)

Communication and Diagnostics

Communication Protocol: HART (Highway Addressable Remote Transducer)

Diagnostics: LED indicators for power, communication, and channel status

Isolation: 500 V galvanic isolation between channels and ground

Dimensions and Weight

Dimensions (L × W × H): 220 × 120 × 60 mm

Weight: Approximately 0.6 kg
