GE IC200ALG432B | Analog Input/Output Module Hot Items Fast Shipping!

Brand：GE Fanuc PLC

Item No.：GE IC200ALG432B

Product origin：USA

Dimensions:120 × 30 × 110 mm

Weight:0.16 kg

Import process is standardized, testing is supported, and after-sales service is guaranteed

Ten thousand models are in stock, quickly matching needs, welcome to call for cooperation!

Product Introduction：

Overview
The GE IC200ALG432B is a mixed analog module from the VersaMax family combining 4 voltage input channels and 2 voltage output channels. It is designed for compact modular control systems where both analog input and output functions are required.

General Information
Brand: GE (General Electric)
Country of Origin: United States
Model Number: IC200ALG432B
Product Type: Mixed Analog I/O Module (4 Inputs / 2 Outputs)
Application: Industrial automation systems requiring both analog inputs and analog outputs in one module

Power Specifications
Supply Voltage: +5 V DC from backplane for logic; +18 to +30 V DC for field circuits
Current Consumption: Approx. 60 mA from logic supply
Inputs: 4 voltage input channels, ±10 V DC
Outputs: 2 voltage output channels, ±10.24 V DC
Protection & Diagnostics: Field-power presence LED, loss of user-side power fault reporting

Communication & Interface
Interface Type: Plug-in onto VersaMax backplane carrier
Channels: 4 single-ended voltage inputs, 2 single-ended voltage outputs
Conversion Resolution: 12-bit analog/digital and digital/analog conversion
Update Rate: Typical 0.4 ms per module
Interface Indicators: LEDs for module status and field circuit power

Environmental
Operating Temperature: 0 °C to +60 °C
Humidity: Up to 95% RH, non-condensing
Installation: Rack or carrier mounted within industrial control cabinet

Dimensions & Weight
Dimensions (L × W × H): Approx. 120 × 30 × 110 mm
Weight: Approx. 0.16 kg

All items are original and new, with sufficient stock and active customer support anytime.

The product channel is compliant, inventory is sufficient, delivery response is efficient, and bulk orders enjoy bargaining rights.
