Honeywell CC-PDOB01 51405043-175 | Digital Output Module 12-Month Warranty 30-Day Returns！

Brand：Honeywell DCS

Item No.：Honeywell CC-PDOB01 51405043-175

Product origin：USA

Dimensions:191 × 188 × 65 mm

Weight:0.3 kg

Original overseas introduction, testing assistance instructions support, stable and reliable service

Flexible stock of various models, support for rapid response, welcome to cooperate and communicate!

Product Introduction：

Overview
The Honeywell CC-PDOB01 51405043-175 is a 32-channel digital output module designed for industrial control systems. It provides reliable 24 V DC discrete outputs, integrates advanced diagnostics and isolation features, and supports system redundancy for high-availability operation.

General Information
Part Number: CC-PDOB01 51405043-175
Manufacturer: Honeywell International Inc.
Brand / Country of Origin: Honeywell / USA
Type: Digital Output Module (32 Channels)
Mounting: Plug-in I/O rack installation
Technology: Bussed 24 V DC outputs, galvanic isolation, fuse-less short-circuit protection

Power Specifications
Supply Voltage: 24 V DC
Load Voltage: 15-30 V DC maximum
On-State Current: Up to 0.5 A per channel in normal conditions
Off-State Leak Current: ≤ 0.5 µA
Turn-On/Turn-Off Time: ≤ 10 ms
Galvanic Isolation: 1500 V AC RMS or ±1500 V DC between outputs and logic

Communication & Interface
Interface: I/O backplane connection to controller system
Output Channels: 32 discrete outputs
Diagnostics: Per channel monitoring, open-wire detection, short-circuit isolation, configurable fail-safe (FAILOPT) behaviour
Redundancy: Supports dual-module redundant installation for continuous operation

Environmental
Operating Temperature: −40 °C to +70 °C
Humidity: Up to 95% RH, non-condensing
Installation Environment: Standard industrial control cabinet

Dimensions & Weight
Dimensions (L × W × H): Approx. 191 × 188 × 65 mm
Weight: Approx. 0.30 kg
