GE DS200IPCDG1ABA | IGBT P3 Snubber Board Hot Items Original

Brand：GE Fanuc PLC

Item No.：GE DS200IPCDG1ABA

Product origin：USA

Dimensions:180 × 130 × 35 mm

Weight:0.5 kg

Original source, data support test content, efficient after-sales processing

Regular models are in stock for a long time, inventory is stable, welcome to inquire about prices!

Product Introduction：

Overview

The GE DS200IPCDG1ABA is an IGBT P3 snubber board used in GE industrial drive systems. It provides critical suppression of voltage spikes, supports IGBT switching protection, and stabilizes high-power inverter operation to ensure long-term reliability of the power module.

General Information

Part Number: DS200IPCDG1ABA
Manufacturer: GE (General Electric)
Series: GE Drive Systems
Type: IGBT Snubber Board
Mounting: Installed within drive power module
Technology: High-voltage snubber circuits, fast-response suppression network
Country of Origin: United States

Power Specifications

Input: High-voltage DC from the inverter power stage
Function: Absorbs switching spikes and redistributes transient energy
Protection: Over-voltage suppression, transient energy damping
Indicators: None

Communication & Interface

Interface Role: Works directly with IGBT power module terminals
Connectivity: High-current terminal connections and board-to-module harness
Diagnostics: Hardware-level electrical testing only
Operator Interface: None
Reset Features: Not applicable (passive protection circuitry)

I/O & Channels

Inputs: High-energy switching transients
Outputs: Stabilized voltage profile across IGBT devices
External Load Support: Not intended for external I/O
Function: Protects IGBT modules from surge and switching stress

Environmental

Operating Temperature: −30 to +70 °C
Humidity: Up to 95% RH, non-condensing
Installation: Inside protected industrial drive enclosure

Dimensions & Weight

Dimensions (L × W × H): 180 × 130 × 35 mm
Weight: ~ 0.5 kg

100% new and original stock ready for shipping — customer assistance 24/7.

This product is suitable for many types of applications, fast delivery, and bulk purchases support more cost-effective quotation methods.
