Triconex 9563-810 7760059030 | Digital Input Termination Panel 100% New 100% New

Brand：Invensys Triconex

Item No.：Triconex 9563-810 7760059030

Product origin：USA

Dimensions:312 × 50 × 112 mm

Weight:1.5 kg

Formal channel supply, complete information can be checked, and supporting service guarantee

There are rich models in stock, which support quick docking of procurement needs. Welcome to inquire for details!

Product Introduction：

Overview
The Triconex 9563-810 is a digital input termination panel designed for use with 24V DC digital input modules in Triconex v9 and v10 systems. It provides 16 input points with commoned power terminals (PWR+ and PWR–), each protected by a fuse with a blown-fuse indicator. This panel is compatible with 32-point digital input modules, requiring two panels for each module.

General Information

Model Number: 9563-810

Type: Digital Input Termination Panel

Compatibility: Triconex v9 and v10 systems

Country of Origin: USA

Power Specifications

Operating Voltage: 24V DC

Power Terminals: Commoned (PWR+ and PWR–)

Leakage Current per Point:

Maximum: 3.3 mA

Typical: 2.5 mA

Fuse Protection: Each input point is protected by a fuse with a blown-fuse indicator

Reason: Because stable and protected power ensures reliable operation in industrial environments.

Communication & Interface

Interface Type: Terminal block connections for field wiring

Number of Input Points: 16

Function: Facilitates secure and organized wiring for digital input signals from field devices to the Tricon controller.

Modules Compatible:

3503E: 24V AC/DC, commoned in groups of 8, TMR with self-test

3505E: 24V DC, low-threshold, commoned in groups of 8 with self-test, TMR

Usage: Two termination panels are required for each 32-point module.

Environmental

Operating Temperature Range: −40 °C to +70 °C

Storage Temperature Range: −40 °C to +85 °C

Humidity: 5% to 95% RH, non-condensing

Protection Rating: IP20

Reason: Because industrial environments require robust and reliable controllers.

Dimensions & Weight

Dimensions: Approximately 312 × 50 × 112 mm

Weight: About 1.5 kg

Authentic and brand-new products in stock, supported by live quote service.

The product information is complete, the delivery cycle is short, and special price services can be supported for bulk orders.
