Product Introduction：

Overview

The Honeywell CC‑TDOD51 51307087‑175 is a high‑density digital output module designed for the Experion® Process Knowledge System (PKS) Series C I/O platform. It provides 32 channels of 24V DC digital outputs, suitable for controlling field devices such as solenoid valves, relays, and actuators in industrial automation applications.

General Information

Brand: Honeywell

Model: CC‑TDOD51

Part Number: 51307087‑175

Product Type: Digital Output Module

System Compatibility: Experion® PKS Series C I/O

Application: Industrial automation, process control, actuator control

Power Specifications

Supply Voltage: 24V DC

Output Voltage Range: 15–30V DC

Output Current:

Per Channel: 0.1A (maximum)

Per 8 Channels: 0.8A (maximum)

Per Module: 3.2A (maximum)

Off-State Voltage: 24V (typical)

Off-State Leakage Current: 100µA (maximum)

Communication & Interface

Output Type: SINK (Open Drain)

Load Voltage: 15–30V DC

Load Current: 0.1A per channel (maximum)

On-State Voltage: 0V (at 0.1A load current)

Off-State Voltage: 24V (typical)

Off-State Leakage Current: 100µA (maximum)

Environmental

Operating Temperature: 0°C to +60°C

Storage Temperature: –40°C to +70°C

Humidity: 5% to 95% non-condensing

Protection Rating: IP20 (when installed inside an enclosure)

Dimensions & Weight

Dimensions: 12.7 cm × 5.1 cm × 12.7 cm

Weight: 0.1 kg
