Honeywell 8C-PAZH52 | Analog Output Module Price Advantage 12-Month Warranty

Brand：Honeywell DCS

Item No.：Honeywell 8C-PAZH52

Product origin：USA

Dimensions:130 × 35 × 150 mm

Weight:0.25 kg

Original imported channel supply, support for testing instructions, worry-free after-sales

The model covers a wide range, and the delivery is efficient. Welcome to contact us for information!

Product Introduction：

Overview
The Honeywell 8C-PAZH52 is an analog output module used in Honeywell Experion Series 8 and C300 control systems. It provides precise analog output signals to field devices for industrial automation and process control applications.

General Information
Part Number: 8C-PAZH52
Manufacturer: Honeywell
Series: Series 8 I/O
Type: Analog Output Module
Mounting: Installed on Series 8 IOTA/IOPM base
Function: Sends analog control signals to field instruments

Power Specifications
Supply Voltage: 24 V DC (backplane powered)
Power Consumption: ≤ 8 W
Input Source: From IOPM
Protection: Built-in over-voltage and short-circuit protection
Indicators: Status LEDs for power and output

Communication & Interface
System Interface: Communicates with C300 via IOPM
Signal Type: Analog output channels
Diagnostics: Module health, output monitoring, fault detection
Configuration: Via Experion engineering tools
Reset Features: Supports software reset

I/O & Channels
Channel Type: Analog output
Number of Channels: 8 or 16 channels (model dependent)
Output Range: 4–20 mA / 0–10 V selectable
Isolation: Channel-to-system isolation
External Load Support: Can drive standard field devices

Environmental
Operating Temperature: −20 to +70 °C
Humidity: 5–95% RH, non-condensing
Protection Rating: IP20 for industrial cabinet mounting

Dimensions & Weight
Dimensions (L × W × H): 130 × 35 × 150 mm
Weight: ~ 0.25 kg

We supply only brand-new original goods, available immediately with live support.

The product supply is stable, the delivery time is short, and the price is moderate. If there is a bulk demand, a separate quotation can be made.
