GE DS200QTBAG1ADC | Terminal Board Rave reviews 30-Day Returns！

Brand：GE Fanuc PLC

Item No.：GE DS200QTBAG1ADC

Product origin：USA

Dimensions:212 × 150 × 35 mm

Weight:0.4 kg

Regular channels, complete test instructions, and responsive services

Large stock, diverse series, adapted to different working conditions, welcome to consult!

Product Introduction：

Overview

The GE DS200QTBAG1ADC is a termination board used in GE Mark V turbine control systems. It provides organized signal wiring for speed pickups, servo outputs, LVDT position sensors, and auxiliary analog inputs. The board acts as the interface between field instrumentation and the Mark V control modules, ensuring clean signal routing and stable connectivity.

General Information

Part Number: DS200QTBAG1ADC

Manufacturer: GE (General Electric)

Series: Mark V Series

Type: Terminal / Termination Board

Mounting: Panel or cabinet mounting with screw fasteners

Technology: Passive signal distribution for speed, servo, and LVDT channels

Power Specifications

Supply Voltage: Not required (passive board)

Power Consumption: None

Input: Accepts sensor and actuator signals routed to controller

Protection: Built-in jumpers for signal configuration and noise-reduction design

Indicators: None

Communication & Interface

Interface Type: Terminal block input/output and 40-pin ribbon connector

Signal Support: Speed pickup signals, LVDT excitation/feedback, servo outputs, analog signals

Diagnostics: Signal routing only (no active diagnostics)

Operator Interface: Terminal blocks and selectable jumpers

Reset Features: Not applicable

I/O & Channels

Relay Channels: None

External Load Support: None (signal wiring board only)

Supported Signals: Magnetic pickup, LVDT, servo valve control signals, analog feedback

Environmental

Operating Temperature: −30 to +65 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: Suitable for cabinet-mounted industrial environments

Dimensions & Weight

Dimensions (L × W × H): 212 × 150 × 35 mm

Weight: ~ 0.40 kg

Brand-new originals directly supplied, 24/7 customer support, quotes provided instantly.

This product is an imported conventional model, with timely delivery. For large purchases, we welcome targeted quotation consultation.
